Specifications
PROCESSOR
SMARTFUSION 2 FPGA SOC
PROCESSOR CLOCK
166 MHz
CODE MEMORY
INTERNAL: 256 KB (SEU IMMUNE ENVM DEDICATED FOR PROGRAM)
DATA MEMORY
EXTERNAL: 16 MB (SPI FLASH)
EXTERNAL: 16 GB (SLC NAND)
REMOVABLE: 2 X 32 GB (SD CARD)
RAM
EXTERNAL: 8 MB (LPDDR)
INTERNAL: 64 KB (ESRAM)
DEBUG INTERFACE
1 x UART
1 x JTAG
ON BOARD COMMUNICATION INTERFACES
2X LVDS
3 X I2C
2 X RS-422
3 X TTC UART
15 X GPIO WITH REMAP CAPABILITY
(CAN BE CONFIGURED TO UART, I2C OR SPI)
ON BOARD PERIPHERALS
1 X BNO055 IMU
1 X TEMPERATURE SENSOR
1 X REAL TIME COUNTER (RTC)
1 X EXTERNAL WATCHDOG TIMER
SUPPLY VOLTAGE
3.3V
POWER
<1W
1 x JTAG
DIMENSIONS
PC104 FORM FACTOR
MASS
<100G
OPERATING TEMPERATURE
-30°C TO 85°C
