Specification
BUS VOLTAGE
16.8V (NOMINAL) CAN BE CONFIGURED ON REQUEST
MAXIMUM POWER POINT TRACKING (MPPT)
4 CHANNELS INPUT FROM SOLAR PANEL
INPUT VOLTAGE: >=18V
OUTPUT VOLTAGE: 16.8
MAXIMUM OUTPUT CURRENT: 3A
OTHER FEATURES
VOLTAGE, CURRENT AND TEMPERATURE (VIT) MEASUREMENT
SATELLITE DEPLOYMENT SENSING
CHANNELS FOR BATTERY HEATER
OVER CHARGING PROTECTION FOR BATTERIES
OUTPUT CHANNELS
CHANNEL1: 3.3V CHANNELS AT 3A
CHANNEL2: 1 X 5V – 6V CHANNEL AT 3A
CHANNEL3: 2 X 12V CHANNEL AT 2A WITH INDIVIDUAL SWITCHES
CHANNEL3: 3 X 12V CHANNEL AT 4A WITH INDIVIDUAL SWITCHES
COMMUNICATION WITH C&DH
3 X SPI CHANNELS
